Level Measurement & Tank Loading
Electrical Level Indicators
Snosko Electrical Level Indicators utilise the latest level measurement technology and control systems for tank/vessel level management. They are contactless and designed with a range of safety features.
- Contactless level management
- Use the latest in measurement technology
- Configured to your requirements
- Designed with a range of safety features
- Complies with AS3780 and AS/NZS 3000
- Determine safe liquid levels, quickly and easily
- Can be integrated with ultrasonic, radar and pressure sensors
- Electrical indicators can be powered by a 24V or 240V source
-
Description
-
Downloads
-
Videos
-
Components
-
Description
Electrical Level Indicators
Snosko Electrical Level Indicators utilise the latest in level measurement technology and control systems for tank/vessel level management. They are contactless and are designed with a range of safety features.
Product features
- Can be integrated with ultrasonic, radar and pressure sensors, which are selected based on the medium being stored and size of the tank/vessel
- Can be terminated in a corrosion resistant, sealed enclosure, which prevents harmful chemicals from damaging the control system (can be mounted on the tank, bund or elevated stand)
- The enclosure can be configured to include a touch screen interface, which allows for sensors and alarms to be calibrated and tested in service
- The interface can be configured to include a 4-20mA analogue output for external system monitoring and/or auxiliary system control
- Additional liquid contact switches for bund alarms and/or redundant level control points can be included for critical applications
- A load-in panel with high level cut off for tank filling and an emergency stop (E-Stop) button can also be included for applications where the adjoining vessel is being filled by a remote filling source (i.e., a truck or a pump)
Operational specifications
- Can be adjusted for Snosko tanks and vessels of all sizes and shapes
- Includes standard connections (flanges, threads etc) for easy attachment
- Electrical indicators can be powered by a 24V or 240V source
Material specifications
- All external components to be either thermoplastic, vinyl ester GFRP or stainless steel
- All electrical components are enclosed
Chemical applications
- Sodium hypochlorite (bleach)
- Hydrochloric acid
- Sodium hydroxide (caustic)
- Sulfuric acid
- Oxygen scavengers (such as sodium metabisulphite)
- Citric acid
- Coagulants (such as poly-aluminium chloride)
- Fluorosilicic acid
- Wastewater
- Magnesium hydroxide
Relevant standards for installation [Need Image Update]
- AS3780 – The storage and handling of corrosive substances
- AS/NZS3000 – Wiring rules
-
Downloads
-
Videos
-
Components
Case Study
Bulk Sodium Hydroxide Storage for an Australian Chemical Processing Facility
Snosko was asked to design and supply a solution to safely store 7,000L of sodium hydroxide for a chemical processing facility in Australia. Due to the critical nature of the site, the tank needed required leak detection options and the ability to be disassembled for maintenance.
